Descriptions of the Accompaniment Creation Process

The process was divided into the following main steps:

• Reading the notes of a melody from a MIDI file

• Determining the key of a melody

• Chord generation using evolution algorithm

• Adding chords to the initial melody

Some of the steps are described in more detail below. All process located in the AccopmpanimentGenerator class and performed using the generate method.

Reading the notes of a melody from a MIDI file

The mido library is used to work with *.mid files in Python. The file is opened, all the notes of the melody are read and they are divided into groups. All this is implemented in the divide_melody_by_parts method

Determining the key of a melody

The algorithm is located in the Keys class. The constructor generates a set of all possible major and minor keys with chords that applicable in each key based on the Figure 6 and 7 in Assignment description.

Determination of key consists of the following criteria:

• The number of matching notes. A list of keys that have the largest number of matching notes is determined;

• Among the selected keys, the first and last notes in the melody are analyzed (1 point for the tonic, 0.66 for the dominant and subdominant, 0.33 for the third degree);

• In addition, the number of stable notes in the melody for each key is determined. The key with the most notes gets 1 more point.

The key with the most points is the key of the given melody.

The get_melody_key method returns the key name and a list of the names of all chords in the computed key.

Chord generation using evolution algorithm

To generate the accompaniment, I used a type of evolutionary algorithm - genetic algorithm. The algorithm is located in the EvolutionAlgorithm class. Evolution occurs for each part separately.

The genotype is a musical chord consisting of three notes and one of the following types: major and minor triads, first and second inversions of major and minor triads, diminished chords (DIM), suspended second chords (SUS2), suspended fourth chords (SUS4).

A population is a set of individuals (chords) included in the key of a melody.

The fitness function for the entire population is the generation of a list of fitness values for each individual (chord). It’s implemented in the get_fitness method Fitness values depend on the following criteria:

• The number of notes in a certain part of the melody that are contained in the chord (1 point per match);
• 0.3 points if the melody part is empty and the individual matches the individual from the previous melody part;
• 0.2 points if the melody part is not empty and the individual does NOT match the individual from the previous melody part;
• If a resolution to the tonic is found (enumeration of the seventh and second degrees, followed by the tonic) 10 points if the individual is the tonic and 8 points if the individual is the dominant;
• If a resolution to a dominant is found (search of the fourth and a procession of steps, followed by a dominant), 10 points if the individual is a dominant;
• 0.1 point if the root of the chord is the same as the first note in the melody part;
• 0.1 point if the root of the chord is the same as the last note in the melody part;
• 0.2 points if chord type is triad.

Crossover is a point crossing, which is implemented in the crossover method and occurs as follows:

• Two parents (chords) are randomly selected from the population;
• As a result of crossing, two children (triad chords) are created, which are the middle between the parents. For example, in the key of C, two parents C and F were chosen. Therefore, the offspring will be A and D;
• For the population, the crossing process is repeated 10 times.

Mutation is implemented in the mutation method and represent the process of choosing a random representative of the offspring and changing its chord type to DIM, SUS2 or SUS4. For the population, the mutation process is repeated 5 times.

Selecting is implemented in the selection method and represent the process of sorting fitness for population and offspring. Three worst individuals are removed from the population and three individuals with the highest fitness value are added, which eventually form a new population.

The process of evolution is the generation of a field of 30 individuals for a particular part of a musical melody. Then, for 10 generations, the process of calculating the fitness function, crossing, mutating and selecting suitable individuals for a new population takes place. The result of the output is a repetition of the maximum fitness value 30 times without change or finding a fitness value greater or equal than 10, which demonstrates resolution to the tonic or dominant in the melody.

The result of evolution is two individuals (chords with a certain type) that have the highest fitness value.

Notes of output melodies
